These lifts use a column mounted to the freight hoist skeleton to attach and elevate the lifting platform. we have designed our goodshoist with the needs of the user as our central focus allows you to select platform dimensions, the lift capacity and the vertical travel for your application.
| (MAX) CAR SIZE | : | 1830mm(WIDTH) x 1830mm(DEPTH) x 2135mm(HEIGHT) / (CUSTOMIZABLE) |
| SHAFT SIZE | : | 2440mm(WIDTH) X 2135mm(DEPTH) / (CUSTOMIZABLE) |
| SAFE WORKING LOAD | : | 300KG TO 1800KG |
| ENCLOSURE (TYPE) | : | EXPENDED METAL / EG PLATE /(RC WALL BY OTHERS) |
| TRAVEL HEIGHT | : | (MAX) 12 METER |
| FLOOR SERVED | : | 4 FLOOR |
| SPEED | : | 6.0m/min - 10.0m/min |
| CONTROL STATION | : | EACH FLOOR WITH FAULT AND LEVER DIGITAL DISPLAY |
| LANDIND DOOR (TYPE) | : | - COLLAPSIBLE GATE C/W SHUTTER |
| - BI-PARTING DOOR | ||
| - SIDE SLIDING DOOR | ||
| CAR | : | EG PLATE FINISH / HAIRLINE STAINLESS STEEL / EXPENDED METAL |
| OPTIONAL FEATURES | : | INTERCOM, SIREN LIGHT, BUZZER |
| DELIVERY | : | NORMALLY AVAILABLE FROM STOCK |
| MAINTENANCE | : | WE RECOMMEND THE LIFT SERVICED INSPECTED 4 TIME A YEAR BY OUR SPECIALIST. THIS IS ENSURE EFFICIENT AND RELIABLE OPERATION |
| ELECTRI SUPPLY | : | 415 VOLT 3PHASE ISOLATOR AT TOP FLOOR DUMBWAITER AREA (BY OTHERS) |
